Use only genuine Yamaha parts for all replacements.
Use oil and grease recommended by Yamaha for all lubrication jobs. Other brands may be similar in function and appearance, but inferior in quality.

Preparation for removal and disassembly
Gaskets, oil seals and o-ringsChecking the piston pin
1. Check:
Piston pin
Blue discoloration/grooves
Replace the
piston pin and then check the lubrication system.
2. Measure:
Piston pin outside diameter "a"
Out of specification Replace
the piston pin.
3. Measure:
Piston pin bore diameter "b"
Out of specifica ...
Troubleshooting method
The engine operation is not normal and the
engine trouble warning light comes on.
1. Check:
Fault code number
a. Check the fault code number displayed on
the FI diagnostic tool.
b. Identify the faulty system with the fault code.
Refer to "Self-Diagnostic Function table".
c. Identi ...
Installing the generator
1. Install:
Woodruff key
Generator rotor
Washer
Generator rotor nut
NOTE:
Clean the tapered portion of the crankshaft and
the generator rotor hub.
When installing the generator rotor, make sure
the woodruff key is properly sealed in the keyway
of the crankshaft.
2. Tighte ...
