1. Check:
2. Check:
3. Hold the vehicle upright and apply the front brake several times.
4. Check:
Refer to "FRONT BRAKE" on page 4-17.
Checking the shift drum assembly
1. Check:
Shift drum groove
Damage/scratches/wear Replace
the shift
drum assembly.
Shift drum segment "1"
Damage/wear Replace the
shift drum assembly.
Shift drum bearing "2"
Damage/pitting Replace the
shift drum assembly.
...
Owner's tool kit
Owner's tool kit
Owner's tool kit
Engine oil drain attachment
The owner's tool kit is located under the
rider seat.
The service information included in this
manual and the tools provided in the
owner's tool kit are intended to assist
you in the performance of preventive
maint ...
Removing the primary drive gear and balancer gears
1. Loosen:
Primary drive gear nut "1"
NOTE:
Place the aluminum plate "a" between the balancer
drive gear "2" and the balancer driven
gear "3", and then loosen the primary drive gear
nut.
2. Straighten the lock washer tab.
3. Loosen:
Balancer driven gear nut "1"
NOTE:
Place ...
