Yamaha YZF-R125 Service Manual: Checking the crankshaft position sensor
1. Disconnect:
- Crankshaft position sensor coupler (from the wire harness)
2. Check:
Crankshaft position sensor resistance
Out of specification
Replace
the crankshaft
position sensor/stator assembly.
a. Connect the pocket tester ( × 100) to the
crankshaft position sensor coupler as shown.
- Positive tester probe
red "1" - Negative tester probe
white "2"
b. Measure the crankshaft position sensor resistance.
Checking the ignition spark gap
1. Check:
Ignition spark gap
Out of specification Perform the
ignition
system troubleshooting, starting with step 5.
Refer to "TROUBLESHOOTING" on page
8-3.
NOTE:
If the ignition spark gap ...
Checking the lean angle sensor
1. Remove:
Lean angle sensor
2. Check:
Lean angle sensor output voltage
Out of specification Replace.
a. Connect the lean angle sensor to the wire
harness.
b. Connect the pocket tester ...
