Circuit diagram
4. Main fuse
5. Main switch
9. Battery
25.ECU (engine control unit)
36.License plate light
37.Tail/brake light
44.Headlight relay
46.Pass switch
47.Dimmer switch
51.Headlight (low beam)
52.Auxiliary light
54.Headlight (high beam)
58.Meter light
60.High beam indicator light
64.Ignit ...
Checking the spark plug
The spark plug is an important engine
component, which is easy to check.
Since heat and deposits will cause any
spark plug to slowly erode, the spark
plug should be removed and checked
in accordance with the periodic maintenance
and lubrication chart. In addition,
the condition of the ...
Checking the rear wheel
1. Check:
Rear wheel axle
Rear wheel
Wheel bearings
Oil seals
Refer to "CHECKING THE FRONT WHEEL"
on page 4-8.
2. Check:
Tire
Rear wheel
Damage/wear → Replace.
Refer to "CHECKING THE TIRES" on page
3-23 and "CHECKING THE WHEELS" on
page 3-25.
3. Measure:
Radi ...
